General information
Model: KTM 990 Adventure
Year: 2007
Category: Enduro / offroad
Rating: 78.1 out of 100. Show full rating and compare with other bikes
Safety: See our safety campaign with the high safety rated bikes in this category.
Engine and transmission
Displacement: 999.00 ccm (60.96 cubic inches)
Engine type: Twin
Stroke: 4
Power: 96.55 HP (70.5 kW)) @ 8500 RPM
Torque: 95.00 Nm (9.7 kgf-m or 70.1 ft.lbs) @ 6500 RPM
Compression: 11.5:1
Bore x stroke: 101.0 x 62.4 mm (4.0 x 2.5 inches)
Fuel system: Carburettor. Mikuni BST 40
Valves per cylinder: 4
Fuel control: DOHC
Ignition: Kokusan digital DC-CDI
Starter: Electric
Lubrication system: Pressure lubrication
Cooling system: Liquid
Gearbox: 6-speed
Transmission type
final drive: Chain
Clutch: Wet multi-disc clutch, operated hydraulically
Physical measures
Dry weight: 199.0 kg (438.7 pounds)
Seat height: 860 mm (33.9 inches) If adjustable, lowest setting.
Ground clearance: 261 mm (10.3 inches)
Wheelbase: 1,570 mm (61.8 inches)
Chassis and dimensions
Frame type: Tubular chromoly space frame, powder-coated
Rake (fork angle): 26.6°
Trail: 119 mm (4.7 inches)
Front suspension: WP USD Ø 48 mm (1.89
Front suspension travel: 115 mm (4.5 inches)
Rear suspension: WP monoshock PDS with hydr. spring preload
Rear suspension travel: 185 mm (7.3 inches)
Front tyre dimensions: 90/90-21
Rear tyre dimensions: 150/70-18
Front brakes: Double disc
Rear brakes: Single disc
Rear brakes diameter: 240 mm (9.4 inches)
Exhaust system: 2 x premium steel with three-way-catalyser
